I. Chassis | ||
1 | Chassis Brand | Sinotruk |
2 | Engine Power | 310HP |
II. Boom system | ||
1 | Max. Vertical height(M) | 38 |
2 | Max. Horizontal Concrete Placing radius (M) | 34 |
3 | Concrete placing depth(M) | 25 |
4 | Control mode | Electric proportion |
5 | Folding type of boom | RZ type |
6 | Folding type of boom | 360° |
7 | Opening mode of landing leg | X-R |
8 | Length of end hose (MM) | 3000 |
9 | Concrete delivery pipe dia. | 125 |
III. Electric Control System | ||
1 | Working voltage: | 24 |
IV. Hydraulic transmission system | ||
1 | Type of hydraulic system | Open type |
2 | System working pressure (Mpa) | 31.5 |
3 | Displacement of main hydraulic oil pump (ml/r) | 190 |
4 | Hydraulic fuel tank capacity (l) | 600 |
5 | Cooling mode of hydraulic oil | Forced-air Cooling |
6 | High-low pressure changeover valve | None |
VII. Pumping system | ||
1 | Form of concrete distribution valve | S Valve |
2 | concrete cylinder | 230 |
3 | Maximum feeding height (MM) | 1500 |
4 | Hopper capacity (M3 ) | 0.65 |
5 | Slump of pumped concrete | 160-220 |
6 | Dimension of allowable maximum aggregate (MM) | 40 |
