| Max. rated lifting capacity | 55t |
| Base boom length | 10.6m |
| Max. length boom | 41m |
| Max. length boom+Jib | 57m |
| Overall length | 12736mm |
| Overall width | 4800/3360extension/retraction |
| Total mass in travel state | 62000kg |
Maximum rated lifting weight 55t
41m main boom + 16m fixed jib, the widest operating range in the industry
Strong performance, leading the industry's 60t-level product performance
Crawler beam + counterweight with self-disassembly technology, no need the auxiliary crane when disassembly
Mainbody transport: weight <28.6t, width <3.0m, meet the requirmentof 1.2m pallet truck.The core accessories are imported and domestic first-line brands with high reliability.
| Max. rated lifting capacity | 55t |
| Base boom length | 10.6m |
| Max. length boom | 41m |
| Max. length boom+Jib | 57m |
| Overall length | 12736mm |
| Overall width | 4800/3360extension/retraction |
| Total mass in travel state | 62000kg |
