Professional customization, preferred in the industry.
♦ Multiple optional configurations are available to easily meet individual customization needs.
♦ With reference to international standards, good expandability is ensured.
♦ The structure is compact and uses high-strength steel, resulting in a lighter overall weight.
♦ Advanced hydraulic system improves the speed of the boom's extension and achieves anti-vibration, multi-action linkage, and proportional action functions of the boom.
| Rated load | 60000kg |
| Rated lifting capacity | 120t.m |
| Max. working range | 18.7m |
| Maximum lifting height | 22.2m |
| Number of boom sections | 8sections |
| Maximum angle of elevation | 80° |
| Swing angle | 360° |
| Support leg spread | 8170mm |
| System displacement | 108L/min |
| Crane self-weight | 18000kg |
| System rated pressure | 32mpa |
