Municipal sanitation is sufficient for the job.
♦ Four-section extendable boom, maximum working range of 12.5 meters, optional six-section extendable boom.
♦ The main body plate of the crane is made of high-strength steel, ensuring structural strength while the weight of the crane is only 3850kg.
♦ Customized hydraulic key components to enhance product competitiveness.
♦ Optional four-section extendable boom
♦ Complies with domestic and international standards and regulations.
| Rated load | 9400kg |
| Rated lifting capacity | 23.8t.m |
| Max. working range | 12.5/16.8m |
| Maximum lifting height | 18.2m |
| Number of boom sections | 5sections |
| Maximum angle of elevation | 86° |
| Swing angle | 360° |
| Support leg spread | 5630mm |
| System displacement | 55L/min |
| Crane self-weight | 3500kg |
| System rated pressure | 30mpa |
