Multi-functional "Little Prince"
♦ The key structural components are welded with Q690 high-strength steel plate, which has high strength and light weight.
♦ The rated torque of the slewing reducer is 6500 N.m, which is the maximum torque among its peers, resulting in stronger operational capacity.
♦ The octagon boom has a light weight and a 15% higher carrying capacity compared to the same tonnage hexagon boom.
♦ The maximum operating range is 17.3 meters, which is about 2.5 meters longer than the mainstream four-section boom models in the market, satisfying more working conditions.
♦ The dual extendable cable has a load-bearing extension safety factor 40% higher than the industry's same level.
| Rated load | 12000kg |
| Rated lifting capacity | 30t.m |
| Max. working range | 17.6m |
| Maximum lifting height | 20m |
| Number of boom sections | 5sections |
| Maximum angle of elevation | 75° |
| Swing angle | 360° |
| Support leg spread | 6000mm |
| System displacement | 84L/min |
| Crane self-weight | 4500kg |
| System rated pressure | 30mpa |
