| Max. Thrust-pull Force | 88kN |
| Max. Torque | 3000N·m |
| Engine Power | 53.7kW |
| Engine Model | YANMAR 4TNV98CT |
| Emission standard | EU V |
| Max. Thrust-pull Speed | 54m/min |
| Max. Rotation Speed | 240r/min |
| Max. Mud Flow | 150L/min |
| Drill Pipe | ∅52×3.048mm×m |
| Max. Entry Angle | 18° |
| Max. Reaming Dia. | ∅500mm |
| Weight | 5.7t |
| Dimension | 5700×1430×2000L×W×H |
