Specifications | Unit | FOG06 | FOG06H | FOG08 | FOG08H | FOG10 | FOG10H |
Maximum Opening | mm | 1650 | 1650 | 1850 | 1850 | 2050 | 2050 |
Operating Pressure (Cylinder) | kg/cm² | 140-180 | 140-180 | 160-200 | 160-200 | 160-200 | 160-200 |
Oil Flow (Cylinder) | L/min | 80-120 | 80-120 | 100-140 | 100-140 | 130-180 | 130-180 |
Operating Pressure (Motor) | kg/cm² | 120-160 | 120-160 | 120-160 | 120-160 | 120-160 | 120-160 |
Oil Flow (Motor) | L/min | 30-50 | 30-50 | 30-50 | 30-50 | 30-50 | 30-50 |
Loading Capacity | kg | 1100 | 1100 | 1500 | 1500 | 1700 | 1700 |
Number of Tines | n | 5 | 5 | 5 | 5 | 5 | 5 |
Suitable Carriers | ton | 12-16 | 17-24 | 25-35 | |||
