Specifications | Unit | FGS03 | FGS04 | FGS06 | FGS08 | FGS10 |
Maximum Opening | mm | 1300 | 1400 | 1800 | 2300 | 2500 |
Operating Pressure (Cylinder) | kg/cm² | 110-140 | 120-160 | 150-170 | 160-180 | 160-180 |
Oil Flow (Cylinder) | L/min | 30-55 | 50-100 | 90-110 | 100-140 | 130-170 |
Operating Pressure (Motor) | kg/cm² | 60-90 | 60-90 | 120-160 | 120-160 | 120-160 |
Oil Flow (Motor) | L/min | 20-30 | 20-30 | 30-50 | 30-50 | 30-50 |
Loading Capacity | kg | 1500 | 2000 | 3000 | 5000 | 8000 |
Suitable Carriers | ton | 4-6 | 7-11 | 12-16 | 17-24 | 25-35 |
