Efficient
Brand-name engine and brand-name hydraulic system, large-displacement main pump and rotary motor, work efficiently.
Reliable
The combination of forging and welding of moving arm and bucket rod, honeycomb bushing, wear-resistant bucket and other features make the whole machine more reliable.
Comfortable
One button start, large screen display, the whole machine control more comfortable.
| Operating Weight | 31300kg |
| Bucket Capacity | 1.65m³ |
| Rated Power | 212kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 11400X3205X3400mm |
| Max.Digging Radius | 11101mm |
| Max.Digging Height | 10120mm |
| Max.Digging Depth | 7357mm |
| Max.Unloading Height | 7400mm |
| Bucket Digging Force | 218kN |
| Stick Digging Force | 169kN |
| Track Width | 600mm |
