Efficient
Weichai + Linde hydraulic powertrain technology, self-identifying working condition power allocation system, overall work efficiency improved by 10% compared to the E series, and fuel efficiency increased by more than 15%.
Reliable
Weichai high-end H platform engine with a lifespan of up to 30,000 hours, Weichai Linde powertrain with a 5-year or 10,000-hour warranty, large cross-section three-stage boom, forged axle seat, more reliable.
Safe and comfortable
New structure F series cab, optimized air conditioning ducts and vents, low ventilation resistance and noise, fast temperature adjustment; Cab meets FOPs & ROPs regulations, making driving safer.
| Operating Weight | 41500kg |
| Bucket Capacity | 2.2m³ |
| Rated Power | 247/2000kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 11860*3490*3844mm |
| Max.Digging Radius | 10790mm |
| Max.Digging Height | 10055mm |
| Max.Digging Depth | 6940mm |
| Max.Unloading Height | 7090mm |
| Bucket Digging Force | 245kN |
| Stick Digging Force | 214kN |
| Track Width | 600mm |
