Reliable
Weichai high-end H platform engine with a lifespan of up to 30,000 hours, Weichai Linde powertrain with a 5-year or 10,000-hour warranty, large cross-section three-stage boom, forged axle seat, double support rollers, "U" shaped plate frame, more reliable.
Efficient
Weichai + Linde hydraulic powertrain technology, self-identifying working condition power allocation system, overall work efficiency improved by 10% compared to the E series, and fuel efficiency increased by more than 15%.
Comfortable
New ventilation duct cab, new seat, Lovol's new intelligent control system, intelligent vehicle control, intelligent insurance, onboard PAD, more comfortable operation.
| Operating Weight | 53000kg |
| Bucket Capacity | 3.2m³ |
| Rated Power | 316/1900kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 12205*3340*3907mm |
| Max.Digging Radius | 11544mm |
| Max.Digging Height | 10812mm |
| Max.Digging Depth | 7172mm |
| Max.Unloading Height | 7345mm |
| Bucket Digging Force | 320kN |
| Stick Digging Force | 250kN |
| Track Width | 600mm |
