Efficient
Weichai powertrain perfectly matched, large bucket capacity, large displacement main pump, high torque rotary motor, to ensure that the whole machine works efficiently, fuel consumption is 3-5% lower than competitors.
Reliable
WP7H engine + Linde hydraulic system, assembly supply, 5 years 10000 hours warranty for key parts; large cross-section three-section movable arm, forged shaft seat, the whole machine is more reliable.
Safe and comfortable
the new structure of Generation F cab with optimized air-conditioning channels and air outlets, low ventilation resistance and low noise, fast temperature adjustment; driving meets the requirements of FOPs & ROPS regulations, safer driving.
Easy maintenance
Three-stage parallel integrated fuel system, easy maintenance; Integrated air filter, maintenance interval doubled.
| Operating Weight | 23100kg |
| Bucket Capacity | 1.2m³ |
| Rated Power | 160kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 9625X3180X3200mm |
| Max.Digging Radius | 9875mm |
| Max.Digging Height | 10190mm |
| Max.Digging Depth | 6510mm |
| Max.Unloading Height | 7260mm |
| Bucket Digging Force | 156kN |
| Stick Digging Force | 109kN |
| Track Width | 600mm |
