Reliable
WP7H engine + Linde hydraulic system, assembly supply, a 5-year 10,000-hour warranty for key parts; Large cross-section three-stage boom, forged axle seat, making the entire machine more reliable.
Efficient
Utilizing the W-LCOT adaptive control algorithm, the controller automatically identifies working condition types and dynamically adjusts power matching; Adopting Weichai Linde hydraulic powertrain technology with high-flow main valve and high-flow swing motor, large bucket, overall work efficiency improved by 10% compared to the E series, and fuel efficiency increased by more than 15%.
Intelligent
Newly developed Lovol's intelligent operation system enables power system management, intelligent interaction, automatic recognition of working conditions, auxiliary operation, and personalized customization.
Easy maintenance
Three-stage parallel integrated fuel system, easy maintenance; Integrated air filter, maintenance interval doubled.
| Operating Weight | 26000kg |
| Bucket Capacity | 1.5m³ |
| Rated Power | 160/2000kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 10040*3180*3322mm |
| Max.Digging Radius | 10075mm |
| Max.Digging Height | 10235mm |
| Max.Digging Depth | 6645mm |
| Max.Unloading Height | 7270mm |
| Bucket Digging Force | 178kN |
| Stick Digging Force | 128kN |
| Track Width | 1471mm |
