Configuration selling point
Equipped with a high-power engine from an industry leading brand, the machine boasts exceptional performance and robust power, all while ensuring fuel efficiency. Its design incorporates a dedicated low fuel consumption zone, tailored to the load cycling characteristics of excavators.Ease of maintenance and operation comfort
The machine is equipped with an intelligent electronic control system, enabling convenient operation and precise actions. The carefully adjusted machine actions deliver smooth and coordinated performance. Furthermore, the machine offers a spacious maintenance area, allowing for easy access during inspections and maintenance.Adaptability to diverse working conditions
The machine offers an easy combination with booms, bucket rods, buckets, and other attachments of varying specifications. It provides multiple working modes and gear settings to meet the requirements of diverse working conditions.| Operating weight | 24800kg |
| Engine power | 133/2000kW/rpm |
| Bucket capacity | 1.2m³ |
| External dimensions | 9985*3180*3235mm |
| Bucket rod digging force | 125kN |
| Bucket digging force | 172kN |
| Rotating speed | 0-11r/min |
| Travel speed | 3.5/5.1km/h |
| Maximum digging height | 10180mm |
| Maximum digging distance | 10198mm |
| Maximum digging depth | 6864mm |
| Emissions | Eu stage IIIndicated as per international standards |
