With Commins high pressure common-rail electronic injection engine, XE150E meets Euro V emission standard and realizes the optimal fuel injection control. The power and torque are improved by more than 10% comparing to the last generation product. Combined with the DOC+DPF exhaust + SCR processing technology, XE150E can effectively handle dust and other hazardous substance in the exhaust. Therefore, it meets the requirements of energy conservation and environment protection. A large number of structural parts developed and manufactured using the special process and imported high-strength and wear-resistant steel are used; strength and service life of products are improved, and various severe working conditions can be easily handled.
| Operating weight | 16600Kg |
| Rated power | 90kW/rpm |
| Engine model | Cummins B4.5 |
| Bucket capacity | 0.6m³ |
| Emission standard | Euro V |
| Maximum torque/speed | 500/1500N.m |
| Displacement | 4.5L |
| Travel speed | 4.7/2.9km/h |
| Swing speed | 11.3r/min |
| Bucket digging force | 107kN |
| Arm digging force | 80kN |
