With Commins QSL9 engine and customized XCMG torque curve, XE380DK has low-speed and large-torque output and low fuel consumption under the heavy-load mode. With straight-flow air filter, it can meet requirements in medium- and heavy- gray conditions; with low intake resistance, it can reduce engine fuel consumption and prevent the engine from early grinding. The detachable pre-filtration function is integrated and the full-life filtration efficiency is over 99.99%. The large capacity rock bucket with the double circular-arc design structure reduces the resistance during excavation and makes it easier for material loading and unloading.
| Operating weight | 38200Kg |
| Rated power | 214kW/rpm |
| Engine model | Cummins QSL9 |
| Bucket capacity | 1.9m³ |
| Emission standard | National Stage Ⅲ |
| Maximum torque/speed | 1344/1300N.m |
| Displacement | 8.9L |
| Travel speed | 5.6/3.3km/h |
| Swing speed | 9.6r/min |
| Bucket digging force | 292kN |
| Arm digging force | 209kN |
