XCMG XE80DA
  • XCMG XE80DA
  • XCMG XE80DA
  • XCMG XE80DA
D Series

XCMG XE80DA

  • 7730Kg
    Operating weight
  • 46.3kW/rpm
    Rated power
  • Yanmr 4TNV98
    Engine model
View Complete Details
  • Overview
  • Specifications
Overview

With Yanmar engine, XE80DA has sufficient low-speed torque reserves, strong power, good fuel economy, low noise and low vibration. With the large displacement electronically controlled main pump, the whole oil consumption is low. It is easily capable of heavy-duty excavation, breaking and other harsh working conditions with strengthened working device, the service life is increased by more than 15%. The bucket capacity is increased, which improves the excavation efficiency. Increased wear-resistant of plate material increases the service life of the bucket by more than 10%. The high-torque automatic two-speed motor can automatically switch the walking gear according to the driving resistance, the walking operation efficiency is higher.

Specifications
Operating weight 7730Kg
Rated power 46.3kW/rpm
Engine model Yanmr 4TNV98
Bucket capacity 0.35m³
Emission standard National Stage Ⅲ
Maximum torque/speed 239.1/1650N.m
Displacement 3.319L
Travel speed 5.0/2.7km/h
Swing speed 11r/min
Bucket digging force 57kN
Arm digging force 38kN
