Reliable
Weichai Baudouin 8M33 large bore engine, Linde hydraulics, heavy-duty swing platform, split mining-specific chassis, newly upgraded work device structure with casting and welding combination, lifespan exceeding 15,000 hours.
Efficient and Energy-saving
8M33 high-power engine, fully electronically controlled Linde high displacement hydraulic system, independent cooling for water and oil, 10 cubic meter large capacity wear-resistant bucket, 15% higher work efficiency and 20% higher fuel efficiency compared to competitors.
Comfortable
Newly upgraded cab and seats, Lovol's intelligent operation system, 10-inch display screen, 360° panoramic view, more comfortable operation.
Easy maintenance
Newly designed maintenance channel and compartment, fully automatic lubrication + semi-automatic grease gun, easier maintenance.
| Operating Weight | 145000kg |
| Bucket Capacity | 8（standard bucket）m³ |
| Rated Power | 680/1800kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 15585*5605*6215mm |
| Max.Digging Radius | 14058mm |
| Max.Digging Height | 13311mm |
| Max.Digging Depth | 7838mm |
| Max.Unloading Height | 8289mm |
| Bucket Digging Force | 667kN |
| Stick Digging Force | 610kN |
| Track Width | 750mm |
