Efficient
LOVOL exclusive engine with high torque and low fuel consumption; energy-saving compact main valve with high flow and low pressure loss.
Reliable
Engines, pumps, valves, motors, cylinders, controllers, etc. are equipped with first-class resources in the industry, the cab meets the requirements of ROPS and FOPS, and the fork and rear seat of the moving arm are made of alloy cast steel, which improves the life expectancy by 20%.
Comfortable
Air-conditioned cab, humanised design, LED lights, large screen display, more comfortable to operate.
| Operating Weight | 12200kg |
| Bucket Capacity | 0.55m³ |
| Rated Power | 86kW |
| Emissions | Stage III |
| Transportation Dimensions（L*W*H） | 7320X2505X2850mm |
| Max.Digging Radius | 7780mm |
| Max.Digging Height | 7950mm |
| Max.Digging Depth | 5030mm |
| Max.Unloading Height | 5600mm |
| Bucket Digging Force | 91kN |
| Stick Digging Force | 68kN |
| Track Width | 500mm |
