Reliability
Equipped with a world-renowned engine and hydraulic system, the cab meets ROPS and FOPS standards, and the boom's front fork and rear seat use alloy cast steel components, increasing lifespan by 20%.
High Adaptability
Equipped with China II engine, this machine demonstrates strong adaptability to various fuel qualities.
Convenient Maintenance
A simple structure makes the machine easy to maintain.
| Operating Weight | 13850kg |
| Bucket Capacity | 0.6m³ |
| Rated Power | 72.7kW |
| Emissions | Stage II |
| Transportation Dimensions（L*W*H） | 7680X2505X2850mm |
| Max.Digging Radius | 8300mm |
| Max.Digging Height | 8500mm |
| Max.Digging Depth | 5435mm |
| Max.Unloading Height | 6080mm |
| Bucket Digging Force | 93.2kN |
| Stick Digging Force | 69kN |
| Track Width | 500mm |
