| Operating Weight | 23000kg |
| Engine Power | 124kW/rpm |
| Scope of capacity | 1.0m³ |
| Engine Model | WEICHAI WP7H |
| Engine Displacement | 6.8L |
| Max. Torque | 810N.m |
| Arm length | 2925mm |
| Bucket rod length | 2700mm |
| Forward Speed | 8.6-35.2Km/h |
| Rotary Speed | 10rpm |
| Max. Main Pump Flow | 241×2L/min |
| Transportation dimensions（L*W*H） | 9698*2540*3350mm |
