| Type | No. | Item | Code | Unit | Data |
|---|
| Identification | 1.01 | Manufacturer |
|
| LONKING |
|---|
| 1.02 | Model |
|
| LG60DTBIII | LG80DTBIII | LG100DTBIII |
| 1.03 | Power type |
|
| Diesel |
| 1.04 | Rated capacity | Q | kg | 6000 | 8000 | 10000 |
| 1.05 | Load center | J | mm | 600 |
| Dimensions | 2.01 | STD Max height (with backrest) |
| mm | 3932 | 3932 | 3262 |
|---|
| 2.02 | STD Max lifting height | h1 | mm | 2500 (Free) | 2500 (Free) | 2100 (Free) |
| 2.03 | Overhead guard height | h4 | mm | 2180 |
| 2.04 | Overall length (with fork) | L1 | mm | 4780 | 4995 | 5540 |
| 2.05 | Wheelbase | L2 | mm | 2250 | 2250 | 2800 |
| 2.06 | Front overhang | L3 | mm | 617 | 647 | 700 |
| 2.07 | Rear overhang | L4 | mm | 715 | 900 | 840 |
| 2.08 | Min.ground clearance (Frame/Mast) | m1/m2 | mm | 300/150 | 300/150 | 380/245 |
| 2.09 | Overall width | W1 | mm | 1945 |
| 2.10 | Adjusting range of fork (outside) |
| mm | 300-1805 | 300-1805 | 450-1780 |
| 2.11 | STD Fork size (L5*W*T) |
| mm | 1220×150×60 | 1220×150×80 | 1220×170×70 |
| 2.12 | Front wheel tread | S | mm | 1440 | 1440 | 1430 |
| 2.13 | Rear wheel tread | P | mm | 1500 |
| 2.14 | Min.turning radius | R1 | mm | 3280 | 3500 | 4000 |
| 2.15 | Min aisle width for pallet 1000×1200,crossways |
| mm | 5315 | 5445 | 6400 |
| 2.16 | Min aisle width for pallet 800×1200,lengthways |
| mm | 5315 | 5445 | 6400 |
| Tires | 3.01 | Wheels number, front/rear (X=driven wheels) |
|
| X=4/2 |
|---|
| 3.02 | Tires type |
|
| Solid/Pneumatic | Pneumatic |
| 3.03 | Tires size, front |
|
| 250-15 | 250-15 | 8.25-20-14PR |
| 3.04 | Tires size, rear |
|
| 250-15-16PR | 250-15-16PR | 9.00-16-16PR |
| Other Details | 4.01 | Max.traveling speed, loaded/unloaded |
| km/h | 23/25 | 23/25 | 24/28 |
|---|
| 4.02 | Max.lifting speed, loaded/unloaded |
| mm/s | 510/530 | 480/510 | 330/370 |
| 4.03 | Lowering speed, loaded/unloaded |
| mm/s | 350/300 | 350/300 | 350/300 |
| 4.04 | Max.traction, loaded |
| KN | 64 | 64 | 62 |
| 4.05 | Max.gradient, loaded/unloaded |
| % | 35/20 | 25/20 | 22/20 |
| 4.06 | STD operating weight (with oil & water) |
| kg | 8750 | 10200 | 11900 |
| 4.07 | Axles loading,front/rear (loaded) |
| kg | 13100/1650 | 16400/1800 | 19600/2300 |
| 4.08 | Axles loading,front/rear (unloaded) |
| kg | 3900/4850 | 4000/6200 | 4800/7100 |
| 4.09 | Service brake |
|
| Power brake-pedal |
| 4.10 | Parking brake |
|
| Mechanical-hand brake lever |
| 4.11 | Drive type |
|
| Automatic |
| 4.12 | Number of gear (front/rear) |
|
| 2/2 |
| 4.13 | Fuel tank capacity |
| L | 140 |
| 4.14 | Battery votage/capacity |
| V/Ah | 2×12/90 |
