Configuration selling point
The core components, including the transmission and drive axle, are self-manufactured and meticulously matched with the dedicated engine, resulting in not only low fuel consumption but also substantial traction.Ease of maintenance and operation comfort
The machine features a removable suspension frame, allowing for easy maintenance. It is equipped with an intelligent diagnostic system. The wide-view door frame and adjustable safety seat provide a comfortable driving and riding experience and convenient operation.Adaptability to diverse working conditions
Optional door frames and forks with varying configurations are available to ensure smooth travel and flexible operation, catering to diverse logistics conditions.| Load Weight | 2500kg |
| Maximum lifting height | 4050mm |
| Wheelbase | 1700mm |
| External dimensions | 3730×1125×2080 |
| Load center distance | 500mm |
| Front overhang | 484mm |
| Forward/Backward Tilting Angle of Gantry | 6°/12°° |
| Emissions | EU stage ⅢAIndicated as per international standards |
