Efficient
Euro V engine certification, EGR system without urea consumption, better economic maintenance; Transverse engine layout, smaller space occupation; Independent hydraulic cooling, suction type, reliable and energy-efficient.
Highly adaptive
Hydrostatic drive, wet bridge, rear bridge with differential lock, radial tires, longer maintenance intervals, better adaptability to working conditions
Reliable
Long wheelbase frame, centered articulated arrangement, cast iron counterweight, composite articulation, more reliable.
| Rated Load | 2000kg |
| Operating Weight | 6650kg |
| Bucket Capacity | 1.2m³ |
| Emissions | EU StageⅤ |
| Wheel Base | 2180mm |
| Engine Power | 55.4kW |
| Dimensions（L*W*H） | 5800X2150X2690mm |
| Unloading Height | 2630mm |
| Unloading Distance | 840mm |
| Total Cycle Time | 10.1s |
| Min.Turning Radius | 4660mm |
| Max.Travel Speed | 34km/h |
