Efficient
Weichai National III engine, fixed axle gearbox, single pump split hydraulic system, fast action, high efficiency, fuel-saving.
Reliable
Construction machinery frame, front and rear equidistant articulation, waterproof connectors, 45° cone + O-ring hydraulic seal, more reliable.
Comfortable
Improved standard cab, larger interior space, simple layout, adjustable steering wheel, more convenient operation.
| Rated Load | 1800kg |
| Operating Weight | 6210kg |
| Bucket Capacity | 1.0m³ |
| Emissions | Stage III |
| Wheel Base | 2260mm |
| Engine Power | 60kW |
| Dimensions（L*W*H） | 5700×2140×2920mm |
| Unloading Height | 2500mm |
| Unloading Distance | 840mm |
| Total Cycle Time | 8.2s |
| Min.Turning Radius | 5080mm |
| Max.Travel Speed | 26.0km/h |
