Efficient
Weichai National III engine, fixed axle control box, load-sensing steering system, fast action, high efficiency, fuel-saving.
Reliable
Construction machinery frame, front and rear equidistant articulation, waterproof connectors, 45° cone + O-ring hydraulic seal, composite articulation; Brake dryer ensuring good braking effect.
Comfortable
Integrated floor ETX cab, good sealing, larger interior space, simple layout, adjustable steering wheel, more convenient operation.
| Rated Load | 3500kg |
| Operating Weight | 10740kg |
| Bucket Capacity | 2m³ |
| Emissions | Stage II |
| Wheel Base | 2880mm |
| Engine Power | 105kW |
| Dimensions（L*W*H） | 7230*2425*3200mm |
| Unloading Height | 2930mm |
| Unloading Distance | 1110mm |
| Total Cycle Time | 9.4s |
| Min.Turning Radius | 6010mm |
| Max.Travel Speed | 37km/h |
