Efficient
Optimized transmission system; Flow-amplifying steering and dual pump merging hydraulic system; Overall efficiency improved by 5%, fuel economy improved by 7%.
Reliable
Extended wheelbase of 3300mm, Lovol's patented composite articulation, honeycomb bushings, brake dryer, higher reliability, better suited for heavy loads.
Safe and comfortable
ETX cab with ergonomically designed seats, more comfortable driving experience.
| Rated Load | 5500kg |
| Operating Weight | 17000kg |
| Bucket Capacity | 3.3m³ |
| Emissions | Stage II |
| Wheel Base | 3300mm |
| Engine Power | 162kW |
| Dimensions（L*W*H） | 8360×2980×3380mm |
| Unloading Height | 3100mm |
| Unloading Distance | 1130mm |
| Total Cycle Time | 10.6s |
| Min.Turning Radius | 7010mm |
| Max.Travel Speed | 42km/h |
