Efficient
Medium to long wheelbase, suitable for various working conditions, flow-amplifying steering hydraulic system, higher efficiency.
Reliable
Lovol's patented composite articulation, honeycomb bushings, 24° cone seal, reinforced drive axle, 18-ply front and 16-ply rear tires, higher reliability.
Safe and comfortable
ETX cab integrated with the floor, higher sealing and safety, 4.3-inch large instrument panel, more comfortable driving experience.
| Rated Load | 5000kg |
| Operating Weight | 17010kg |
| Bucket Capacity | 3m³ |
| Emissions | Stage II |
| Wheel Base | 3200mm |
| Engine Power | 162kW |
| Dimensions（L*W*H） | 8060×2980×3380mm |
| Unloading Height | 3140mm |
| Unloading Distance | 1090mm |
| Total Cycle Time | 10.6s |
| Min.Turning Radius | 6930mm |
| Max.Travel Speed | 42km/h |
