Efficient
WP10 Weichai National III engine with electronic throttle; Optimized transmission system; Flow-amplifying steering and dual pump merging hydraulic system; Overall efficiency improved by 5%, fuel economy improved by 7%.
Reliable
Extended wheelbase of 3350mm, new counterweight, Lovol's patented composite articulation, honeycomb bushings, brake dryer, higher reliability, better suited for heavy loads.
Safe and Comfortable
Newly designed cab and seats, LCD display, LED lights, more comfortable driving experience.
Easy maintenance
Three-door engine hood for easy maintenance.
| Rated Load | 5500kg |
| Operating Weight | 17460kg |
| Bucket Capacity | 3.3m³ |
| Emissions | Stage II |
| Wheel Base | 3350mm |
| Engine Power | 162kW |
| Dimensions（L*W*H） | 8590×2980×3420mm |
| Unloading Height | 3100mm |
| Unloading Distance | 1130mm |
| Total Cycle Time | 9.6s |
| Min.Turning Radius | 7140mm |
| Max.Travel Speed | 42km/h |
