Efficient
Weichai dedicated engine, optimized transmission system, variable displacement working and steering hydraulic system, 8% improvement in work efficiency, 5% improvement in fuel economy.
Reliable
Extended wheelbase of 3500mm, world-class engine, ZF transmission, reinforced front and rear axles and frame, wear-resistant bucket, higher overall reliability.
Safe and comfortable
Newly designed cab and seats, FNR integrated hydraulic control handle, LCD display, LED lights, large tires, more comfortable driving experience.
Easy maintenance
Three-door engine hood for easy maintenance.
| Rated Load | 6500kg |
| Operating Weight | 20590kg |
| Bucket Capacity | 4.0m³ |
| Emissions | Stage III |
| Wheel Base | 3500mm |
| Engine Power | 178kW |
| Dimensions（L*W*H） | 9100×3100×3450mm |
| Unloading Height | 3400mm |
| Unloading Distance | 1260mm |
| Total Cycle Time | 10.3s |
| Min.Turning Radius | 7350mm |
| Max.Travel Speed | 38.0km/h |
