Efficient
Weichai dedicated engine, optimized transmission system, variable displacement working and steering hydraulic system, 8% improvement in work efficiency, 5% improvement in fuel economy.
Reliable
Extended wheelbase of 3400mm, ZF transmission, reinforced front and rear axles and frame, wear-resistant bucket, higher overall reliability.
Safe and comfortable
ETX cab with ergonomically designed seats, FNR integrated hydraulic control handle, LCD display, LED lights, air conditioning with mutual exclusion of heating and cooling, more comfortable driving experience.
| Rated Load | 6000kg |
| Operating Weight | 20830kg |
| Bucket Capacity | 4m³ |
| Emissions | Stage III |
| Wheel Base | 3400mm |
| Engine Power | 178kW |
| Dimensions（L*W*H） | 8930x3100x3410mm |
| Unloading Height | 3410mm |
| Unloading Distance | 1290mm |
| Total Cycle Time | 10.3s |
| Min.Turning Radius | 7230mm |
| Max.Travel Speed | 38km/h |
