| Max. Working Height | 16.50m/54ft 2in |
| Max. Platform Height | 14.50m/47ft 7in |
| Max. Operating Range(+0.6m) | 7.75m/23ft 6in |
| Max. Platform Range | 6.55m/21ft 6in |
| Max. Up And Over Clearance | 7.89m/25ft 11in |
| Flatbed Transport Dimensions (L×W×H) | 5.15m×1.73m×2.00m/16ft 11in×5ft 8in×6ft 7in |
| Standard Container Transport | All Applicable |
| Platform Size(Length×Width) | 1.45m×0.90m/4ft 9in×2ft 11in |
| Turntable Tailswing | 0 |
| Ground Clearance | 0.20m/9in |
| Wheelbase | 2.00m/6ft 8in |
| S.W.L(Unrestricted/Restricted) | 230kg/508lb |
| Max. Occupants | 2 |
| Gradeability | 30% |
| Travel Speed(Stowed) | 6.1km/h / 3.9mph |
| Travel Speed(Raised) | 1.1km/h / 0.8mph |
| Max. Working Slope | X-3°/Y-3° |
| Turret Rotation | 360°Discontinuity |
| Platform Rotation | 180° |
| Jib Movement | 130° |
| Main Boom Maximum Angle | 75° |
| Turning Radius(Inside/Outside) | 2.08m/3.30m / 6ft 10in/10ft 11in |
| Tyres | 17.5x6.75 |
| Overall Weight | 6700kg/14770lb |
| Battery | 48V/300Ah |
| Charger | 48V/35A |
| Hydraulic Tank | 30L/7.10gal |
