| Max. Working Height | 18.00m/59ft 1in |
| Max. Platform Height | 16.00m/52ft 6in |
| Max. Operating Range(+0.6m) | 8.30m/27ft 3in |
| Max. Platform Range | 7.70m/25ft 3in |
| Max. Up And Over Clearance | 8.90m/29ft 2in |
| Flatbed Transport Dimensions (L×W×H) | 6.10m×1.73m×2.00m/20ft×5ft 8in×6ft 7in |
| Standard Container Transport | All Applicable |
| Platform Size(Length×Width) | 1.45m×0.76m/4ft 9in×2ft 6in |
| Turntable Tailswing | 0 |
| Ground Clearance | 0.20m/8in |
| Wheelbase | 2.00m/6ft 7in |
| S.W.L(Unrestricted/Restricted) | 230kg/507lb |
| Max. Occupants | 2 |
| Gradeability | 25% |
| Travel Speed(Stowed) | 6.1km/h / 3.8mph |
| Travel Speed(Raised) | 1.1km/h / 0.7mph |
| Max. Working Slope | X-3°/Y-3° |
| Turret Rotation | 360°Discontinuity |
| Platform Rotation | 180° |
| Jib Movement | 130° |
| Main Boom Maximum Angle | 75° |
| Turning Radius(Inside/Outside) | 2.08m/3.30m / 6ft 10in/10ft 10in |
| Tyres | 17.5x6.75 |
| Overall Weight | 7420kg/16358lb |
| Battery | 48V/300Ah |
| Charger | 48V/35A |
| Hydraulic Tank | 30L/7.9gal |
