Max. Working Height | 24.27m/79ft 7in |
Max. Platform Height | 22.27m/73ft 1in |
Max. Operating Range(+0.6m) | 15.29m/50ft 2in |
Max. Platform Range | 14.69m/48ft 2in |
Max. Up And Over Clearance | 8.10m/26ft 7in |
Max. Down Probing Depth | 3.74m/12ft 3in |
Flatbed Transport Dimensions (L×W×H) | 8.80m×2.50m×2.60m/28ft 10in×8ft 2in×8ft 6in |
Standard Container Transport | All Applicable |
Platform Size(Length×Width) | 2.44m×0.91m/8ft×3ft |
Turntable Tailswing | 0.85m/2ft 9in |
Ground Clearance | 0.28m/11in |
Wheelbase | 2.50m/8ft 2in |
S.W.L(Unrestricted/Restricted) | 300kg/661lb |
Max. Occupants | 2 |
Gradeability | 40% |
Travel Speed(Stowed) | 6.0km/h / 3.70mph |
Travel Speed(Raised) | 1.1km/h / 0.70mph |
Max. Working Slope | X-5°/Y-5° |
Turret Rotation | 360°Continuous |
Platform Rotation | 180° |
Jib Movement | 132° |
Main Boom Maximum Angle | -5.5~75° |
Turning Radius(Inside/Outside) | 3.68m/5.54m / 12ft 1in/18ft 2in |
Tyres | 315/55D20 |
Overall Weight | 12000kg/26455lb |
Diesel Engine | Kubota D1105/18.2kW |
Emergency Power System | 12V |
Diesel Tank | 115L/30gal |
Hydraulic Tank | 160L/42gal |
