| Max. Working Height | 5.60m/18ft 4in |
| Max. Platform Height | 3.60m/11ft 10in |
| Overall Length(Without Ladder) | 1.29m/4ft 3in |
| Overall Length(With Ladder) | 1.44m/4ft 9in |
| Overall Width | 0.76m/2ft 6in |
| Overall Height(Rails Up) | 1.99m/6ft 6in |
| Overall Height(Rails Down) | 1.62m/5ft 3in |
| Platform Size(Length×Width) | 1.29m×0.70m/4ft 3in×2ft 4in |
| Platform Extension Size | 0.60m/2ft |
| Ground Clearance(Stowed/Raised) | 0.06m/0.015m / 2in/1in |
| Wheelbase | 1.05m/3ft 5in |
| Turning Radius(Inside/Outside) | 0.40m/1.55m / 1ft 4in/5ft 1in |
| Tyres | φ230×80mm |
| S.W.L | 240kg/529lb |
| S.W.L On Extension | 100kg/220lb |
| Max. Occupants | 2/1 |
| Gradeability | 25% |
| Travel Speed(Stowed) | 4.0km/h / 2.49mph |
| Travel Speed(Raised) | 0.6km/h / 0.37mph |
| Max. Working Slope | X-1.5°/Y-3° |
| Up/Down Speed | 27/20sec |
| Overall Weight(Lead-acid Battery) | 920kg/2028lb |
| Hydraulic Tank | 3L/8pt |
| Battery(Lead-acid Battery) | 24V/85Ah |
| Charger | 24V/15A |
| Driving Motor | 2×24V/0.4kW |
| Lifting Motor | 24V/1.2kW |
