| Max. Working Height | 6.50m/21ft 4in |
| Max. Platform Height | 4.50m/14ft 9in |
| Overall Length(Without Ladder) | 1.43m/4ft 8in |
| Overall Length(With Ladder) | 1.58m/5ft 2in |
| Overall Width | 0.76m/2ft 6in |
| Overall Height(Rails Up) | 2.05m/6ft 9in |
| Overall Height(Rails Down) | 1.68m/5ft 6in |
| Platform Size(Length×Width) | 1.44m×0.74m/4ft 9in×2ft 5in |
| Platform Extension Size | 0.60m/2ft |
| Ground Clearance(Stowed/Raised) | 0.07m/0.016m / 3in/1in |
| Wheelbase | 1.12m/3ft 8in |
| Turning Radius(Inside/Outside) | 0m/1.30m / 0in/4ft 3in |
| Tyres | φ305×100mm |
| S.W.L | 230kg/507lb |
| S.W.L On Extension | 113kg/249lb |
| Max. Occupants | 2/1 |
| Gradeability | 25% |
| Travel Speed(Stowed) | 4.5km/h / 2.80mph |
| Travel Speed(Raised) | 0.6km/h / 0.37mph |
| Max. Working Slope | X-1.5°/Y-3° |
| Up/Down Speed | 22/20sec |
| Overall Weight(Lead-acid Battery) | 1200kg/2646lb |
| Hydraulic Tank | 3.5L/0.7gal |
| Battery(Lead-acid Battery) | 24V/115Ah |
| Charger | 24V/15A |
| Driving Motor | 2x24VDC/0.5kw |
| Lifting Motor | 24VDC/2.2kW |
