| Max. Working Height | 20.20m/66ft 3in |
| Max. Platform Height | 18.20m/59ft 8in |
| Overall Length(With Outriggers) | 5.35m/17ft 7in |
| Overall Width | 2.33m/7ft 8in |
| Overall Height(Rails Up) | 3.31m/10ft 10in |
| Overall Height(Rails Down) | 2.50m/8ft 2in |
| Platform Size(Length×Width) | 5.35m×1.90m/17ft 7in × 6ft 3in |
| Platform Extension Size | 1.10m/1.10m / 3ft 7in/3ft 7in |
| Ground Clearance(Stowed/Raised) | 0.30m / 1ft |
| Wheelbase | 2.94m/9ft 8in |
| Turning Radius(Inside/Outside) | 3.30m/6.40m / 10ft 10in/21ft |
| Tyres | 315/55/D20 |
| S.W.L | 545kg/1202lb |
| S.W.L On Extension | 227kg/500lb |
| Max. Occupants(Indoor/Outdoor) | 4/4 |
| Gradeability | 0.4 |
| Travel Speed(Stowed) | 5.6km/h / 3.48mph |
| Travel Speed(Raised) | 1.0km/h / 0.62mph |
| Max. Working Slope | 2°/3° |
| Up/Down Speed | 84/85sec |
| Overall Weight(With Outriggers) | 10150kg/22377lb |
| Diesel Engine | 37kW/2700rpm |
| Diesel Tank | 90L/23gal |
| Hydraulic Tank | 130L/34gal |
