| Models | S1212Ⅱ | S4046Ⅱ |
| Measurements | ||
| Work Height Max. | 14/9.5m (in/out) | 45'11''/31'2'' (in/out) |
| A-Platform Height-Raised | 12/7.5m (in/out) | 39'4''/24'7'' (in/out) |
| B-Platform Length | 2.26m | 7'5'' |
| C-Platform Width | 1.12m | 3'8'' |
| D-Overall Length | 2.49m | 8'2'' |
| E-Overall Width | 1.18m | 3'10'' |
| F-Overall Height-Guardrails Up | 2.63m | 8'8'' |
| G-Overall Height-Guardrails Down | 1.84m | 6' |
| H-Extension Deck | 0.9m | 2'11'' |
| I-Wheelbase | 1.85m | 6'1'' |
| Ground Clearance(Stowed/Raised) | 100/20mm | 4''/1'' |
| Productivity | ||
| Max. Platform Occupants | 2 (in) /1 (out) | |
| Platform Capacity | 320kg | 705 lbs |
| Platform Capacity-Extension Deck | 120kg | 265 lbs |
| Drive Height | Full Height | |
| Gradeability-Stowed | 25% | |
| Min. Turning Radius | 2.45m | 8' |
| Raise/Lower Speed | 65s/60s | |
| Brakes | Rear-wheel Brake | |
| Drive Mode | 4×2 | |
| Tire Type | Solid Non-marking | |
| Tire Size | 380*130mm | 15''x5'' |
| Ground Pressure, Tyres | 1277 kPa | 185.2 psi |
| Power | ||
| Power Source | 24V (4x6V) 300Ah,FLA | |
| Power Source (Lithium Battery) | 24V 230Ah | |
| Hydraulic System | ||
| Hydraulic Oil Capacity | 23L | 6.1gal |
| Weight | ||
| Machine Weight(CE/ANSI) | 2970kg | 6548 lbs |
