| Work Height | 7.8m|25ft 7in |
| A- Platform Height -Elevated | 5.8m|19ft |
| B - Platform Height Stowed | 1.05m|3ft 5in |
| C- Platform Length | 1.65m|5ft 5in |
| D - Platform Width | 0.74m|2ft 5in |
| Platform Extension | 0.91m|3ft |
| E- Overall Height (RailsUp) | 2.20m|7ft 3in |
| Overall Height (Rails Down) | 1.79m|5ft 10in |
| F- Overall Length | 1.85m|6ft 1in |
| G- Overall Width | 0.76m|2ft 6in |
| H Wheelbase | 1.37m|4ft 6in |
| I- Ground Clearance (Stowed) | 0.06m|2.4in |
| J- Ground Clearance (Raised) | 0.016m|0.65in |
| Platform Capacity | 230kg|510lb |
| Capacity on Deck Extension | 113kg|250lb |
| Max. Number of Workers (Indoor/Outdoor) | Indoor: 2|Indoor: 2 |
| Drive Speed (Stowed) | 3.5km/h|2.2mph |
| Drive Speed (Raised) | 0.8km/h|0.5mph |
| Turning Radius (Inside) | 0.1m|4in |
| Turning Radius (Outside) | 1.6m|5ft 3in |
| Up/Down Drive Motor | 24V/3.3KW|24V/3.3KW |
| Up/Down Time | 20s/24s|20s/24s |
| Gradeability | 25%(14°)|25%(14°) |
| Max. Working Slope (Lateral/Vertical) | 1.5°/3°|1.5°/3° |
| Control | Proportional Control|Proportional Control |
| Drive | Front Wheels|Front Wheels |
| Brake | Rear Wheels|Rear Wheels |
| Tire | Ø305mmx114mm|ф12in×4.5in |
| Battery | 4×6V/170Ah (HOPPECKE)4×6V/180Ah (QUIMO)|4×6V/170Ah (HOPPECKE)4×6V/180Ah (QUIMO) |
| Charger | 24V/30A|24V/30A |
| Gross | 1425kg|3140lb |
