| Work Height Max. | 40.2m(131'11'') |
| Platform Capacity | 300/450kg(661/992lbs) |
| Machine Width | 2.49m(8'2'') |
| Horizontal Outreach | 23.5 m(77'1'') |
| Machine Weight | 20700kg(45635lbs) |
l Lithium battery powered, low noise, zero-emission, maintenance-free, and high-capacity.
l Equipped with X-type leg expansion structure, and adopting magnetostrictive displacement sensor to realize high-accurate, simple and reliable control.
l Adopt three steering modes: front-wheel, crab and pivot steering, to meet the demand of operations in narrow space.
l Four synchronous telescopic booms, improving efficiency by over 30% than that of two-cylinder drive boom telescopic mode.
STANDARD FEATURES
Proportional control
Emergency stop button
Horn/Hour meter
Auto-leveling platform
Descent alarm
Anti-collision protection
Flashing beacons
Over-tilt protection system
Cylinder bellows
Telematics connector
Platform tool box
Overload sensing system
Oscillating axle
Intelligent diagnostic system
Platform control cover
Foam-filled non-marking tires
OPTIONAL
Telematics
Glazier kit
Auxiliary rail
AC power to platform
Half-height mesh platform
Solid tires
Solid non-marking tires
Foam-filled tires
Biodegradable hydraulic oil
| Work Height Max. | 40.2m(131'11'') |
| Platform Capacity | 300/450kg(661/992lbs) |
| Machine Width | 2.49m(8'2'') |
| Horizontal Outreach | 23.5 m(77'1'') |
| Machine Weight | 20700kg(45635lbs) |
