| Working Height | 18280mm |
| Lift capacity | 300(unlimited)kg |
| Weight | 8200kg |
| Overall dimension-Stowed | 9150x2320x2520mm |
| Overall dimension-Transportation | 7500x2320x2600mm |
| Dimension of working platform | 1830x760x1150mm |
| Wheelbase | 2360mm |
| Fly jib length | 1420mm |
| Ground clearance | 240mm |
| Max.Platform height | 16.28m |
| Max.Working range | 12.05m |
| Max.Occupants | 2 |
| Max.Working slope | X-5°/Y-5° |
| Telescopic boom luffing range | -8°～+73.5° |
| Flying jib luffing range | -60°~70° |
| Turntable rotation | 360° |
| Platform rotation | 160° |
| Drive speed | 5.5 km/hstowed |
| Drive speed | 0.6 km/hUp or extended |
| Min.Turning radius | 3200mm/4700 mminside/outside |
| Turntable tailswing | 1520 mmstowed |
| Max.Gradeability | 45% (24°) |
