It is a high-efficiency crushing equipment integrating feeding, crushing and discharging, which is suitable for primary crushing. The equipment is suitable for a wide range of materials, from hard to soft rock, recycled material with or without reinforcement, scrap, bitumen and slag, and is used extensively in mining operations.
The user-friendly equipment characteristic control system optimizes equipment production capacity, simplifies the frequency of operation and maintenance, improves stable production time, and comprehensively improves equipment performance and overall safety.
The oil-electric dual-purpose jaw crusher station can cope with various working conditions and is widely used in mine crushing, bridge tunnels, construction projects, construction waste recycling and other fields. It is suitable for crushing river pebbles, granite, mountain rocks, ore tailings and other materials.
1. Optimize fuel efficiency;
2. Minimised the amount of dust, and Eco-friendly;
3. Electric drive, fuel and electricity dual-purpose, adapt to a variety of complex environments;
4. User-friendly PLC control system and color screen, easy to operate;
5. For impurities in the feed, the iron remover can provide you with maximum production stability;
6. Deep cavity crushing, safe and efficient, improving feeding capacity and output;
7. Simple maintenance and low cost of use;
8. High-performance main engine, hydraulic adjustment of the discharge port of the main engine, safe and reliable.
| Usage | For primary crushing of aggregate processing, solid waste processing, mining, etc., the generator set that comes with the equipment can be used, and the power grid can also be set up. |
| Maximum feeding rate | 350t/h |
| Feeder size | 1060×750 |
| Feeder adjustable size | 50-150mm |
| Power | 240kW |
| Weight | Around 52t |
| Transportational size(L×W×H/mm) | 19000×3200×3920 |
| Operational size(L×W×H/mm) | 19600×7100×5400 |
