Configuration selling point
The machine is equipped with the Weichai WD12 engine and Linde hydraulic components, meticulously matched to create a golden power control assembly. It is further enhanced by the self-developed machine control system, resulting in straightforward control, exceptional efficiency, and fuel savings. The Shantui-specific chassis system consisting of four wheels and one track delivers an extended service life and high reliability.Ease of maintenance and operation comfort
The machine features an integrated positive pressure cab that ensures a low-noise environment. The intelligent touchscreen instrument includes fault self-diagnosis capability. The lightweight and effortless electro-hydraulic controls enable loaded steering and pivot steering. The machine lubrication, engine, hydraulic components, electrical components, and other maintenance parts are all arranged on the exterior of the machine, facilitating convenient maintenance and overhaul.Adaptability to diverse working conditions
Optional configurations include the semi-U blade and three-tooth ripper, catering to diverse operation requirements such as earthmoving and soil loosening.| Overall weight | 20500kg |
| Engine brand | WEICHAI |
| Rated power/rated speed | 185/2100kW/rpm |
| Machine external dimensions | 5465x3709x3312mm |
| Track center distance | 2050mm |
| Track shoe width | 610/660mm |
| Ground contact length | 2980mm |
| Fuel tank capacity | 444L |
| Blade type | Semi-U blade |
| Blade capacity | 6.8m³ |
| Emissions | Eu stageⅡIndicated as per international standards |
