Configuration Selling Point
The Weichai WP13 engine is powerful and efficient,with customized ECU control parameters: large torque reserve, more suitable for matching needs of hydrostatic drive system.
Ease Of Maintenance And Operation Comfort
The working valve is externally located, making maintenance more convenient. The protective cover is side-opening, providing a large space for maintenance. Engine room lights ensures the safety of nighttime inspection and maintenance.
Adaptability To Diverse Working Conditions
The high-mounted drive chassis, double track idlers, and K-shaped suspension can adapt to various working conditions. 43 pieces of 610mm lubricated track shoe bring longer service life. The grounding length is 3880mm, and the minimum ground clearance is 697mm makes the bulldozer smooth operation and the good passability. The 1168L fuel tank meets the operating requirements for at least 14 hours. Standard semi-U-shaped blade and single-tooth ripper is good designed for mining work.
| Overall weight | 42000kg |
| Engine brand | Weichai WP13 |
| Rated power/rated speed | 1800kW/rpm |
| Machine external dimensions | 9381*4130*3635mm |
| Track center distance | 2140mm |
| Track shoe width | 560/660/710mm |
| Ground contact length | 3275mm |
| Fuel tank capacity | 600L |
| Blade type | Semi-U |
| Blade capacity | 10.5m³ |
| Emissions | Eu stageⅢAIndicated as per international standards |
