Configuration selling point
Shantui chassis system is built to be durable. Shantui’s self-developed drive system has been extensively proven in the market, exhibiting commendable durability. When combined with the dedicated engine, it delivers substantial traction;Ease of maintenance and operation comfort
The openable side guard offers a spacious area and the reasonable layout of filter elements and hydraulic components facilitate convenient maintenance. The hexahedral cab is designed with ergonomic considerations and provides a spacious interior and wide field of view;Adaptability to diverse working conditions
Featuring a logging cab and optional attachments such as a straight tilt blade, angle blade, ripper, winch, and more, the machine is designed to meet diverse operational requirements in forest working conditions.| Overall weight | 24700kg |
| Engine brand | Cummins NT855-C280S10/Weichai WP12G240E306 |
| Rated power/rated speed | 175/1800kW/rpm |
| Machine external dimensions | 5495*3725*3402mm |
| Track center distance | 2000mm |
| Track shoe width | 610/660mm |
| Ground contact length | 2730mm |
| Fuel tank capacity | 450L |
| Blade type | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade |
| Blade capacity | 4.6/3.4/5.8/6.7m³ |
| Emissions | Eu stageⅡIndicated as per international standards |
