Shantui SD26F
  • Shantui SD26F
Bulldozer

Shantui SD26F

  • 24700kg
    Overall weight
  • WEICHAI
    Engine brand
  • 206/1900kW/rpm
    Rated power/rated speed
View Complete Details
  • Overview
  • Specifications
Overview

Configuration selling point

Powered by the Weichai WP12 engine and paired with Shantui’s self-developed drive system, the machine delivers robust power. The four wheels and one track self-developed by Shantui ensure reliable quality and an extended service life;

Ease of maintenance and operation comfort

The working valve elements of the hydraulic system are externally placed to facilitate easy maintenance. The hexahedral cab that is designed with ergonomic considerations provides a spacious interior, excellent visibility, and more comfortable operation.

Adaptability to diverse working conditions

Featuring a forest cab, the machine offers enhanced protection for the vehicle body and exhibits remarkable adaptability. It can be equipped with a straight tilt blade, three-tooth ripper, winch, and other attachments to meet the specific requirements of forestry operations;
Specifications
Overall weight 24700kg
Engine brand WEICHAI
Rated power/rated speed 206/1900kW/rpm
Machine external dimensions 5495*3725*3402mm
Track center distance 2000mm
Track shoe width 610/660mm
Ground contact length 2730mm
Fuel tank capacity 450L
Blade type Straight/Angle/U-shape/Semi-U balde
Blade capacity 4.6/3.4/5.8/6.7m³
Emissions Eu stageⅢAIndicated as per international standards
