Configuration selling point
High-power engine, customized large displacement main pump, Weichai + Linde super powerful golden combination + fully electronic control system.Ease of maintenance and operation comfort
The machine is equipped with a 10.1-inch capacitive touchscreen, featuring a full-fitting IPS screen with wide viewing angles and high brightness, ensuring excellent visibility even under sunlight. The machine also provides a spacious maintenance area, allowing for easy access during inspections and maintenance.Adaptability to diverse working conditions
It can be configured with a range of working devices such as rock buckets, breaker hammers, ultra-powerful booms, rippers, and a variety of buckets to meet different working condition requirements.| Operating weight | 66000kg |
| Engine power | 566/1900kW/rpm |
| Bucket capacity | 4m³ |
| External dimensions | 12245*3735*4750mm |
| Bucket rod digging force | 350kN |
| Bucket digging force | 420kN |
| Rotating speed | 0-7.2r/min |
| Travel speed | 3.2/4.7km/h |
| Maximum digging height | 10855mm |
| Maximum digging distance | 11520mm |
| Maximum digging depth | 7040mm |
| Emissions | Eu stage IIIAIndicated as per international standards |
