Configuration selling point
The golden combination of Weichai and Linde, supplemented by the fully electronic control positive-flow hydraulic system, ensures a perfect synergy between load and flow, resulting in significantly improved response speed.Ease of maintenance and operation comfort
The machine is equipped with a 10.1-inch capacitive touchscreen, featuring a full-fitting IPS screen with wide viewing angles and high brightness, ensuring excellent visibility even under sunlight. The machine also provides a spacious maintenance area, allowing for easy access during inspections and maintenance.Adaptability to diverse working conditions
It can be configured with a range of working devices such as rock buckets, breaker hammers, ultra-powerful booms, rippers, and a variety of buckets to meet different working condition requirements.| Operating weight | 76500kg |
| Engine power | 566/1900kW/rpm |
| Bucket capacity | 5m³ |
| External dimensions | 12600*4310*4700mm |
| Bucket rod digging force | 350kN |
| Bucket digging force | 420kN |
| Rotating speed | 0-7.2r/min |
| Travel speed | 3.2/4.7km/h |
| Maximum digging height | 11820mm |
| Maximum digging distance | 11700mm |
| Maximum digging depth | 7150mm |
| Emissions | Eu stage IIIAIndicated as per international standards |
