Configuration selling point
The machine is equipped with a high-end power hydraulic system of a world-class brand. It incorporates fully electronic control hydraulic technology with low pressure loss, an engine with high-combustion efficiency, and precise matching control technology for the hydraulic power system.Ease of maintenance and operation comfort
It incorporates technologies for low noise, low vibration, and ergonomic recognition, as well as an identity recognition anti-theft system. The machine has a spacious maintenance area, allowing for easy access during inspections and maintenance.Adaptability to diverse working conditions
It can be configured with a range of working devices such as rock buckets, ultra-powerful booms, rippers, and a variety of buckets to meet different working condition requirements.| Operating weight | 93500kg |
| Engine power | 574/2100kW/rpm |
| Bucket capacity | 5.6m³ |
| External dimensions | 13720*4485*5025mm |
| Bucket rod digging force | 390kN |
| Bucket digging force | 485kN |
| Rotating speed | 0-6.5r/min |
| Travel speed | 2.82/4.25km/h |
| Maximum digging height | 12715mm |
| Maximum digging distance | 12570mm |
| Maximum digging depth | 7140mm |
| Emissions | Eu stage IIIAIndicated as per international standards |
