Configuration selling point
Equipped with a high-power engine, the machine delivers robust power, exceptional efficiency and energy savings. Additionally, it is equipped with a large-displacement main pump and a fully electronic control hydraulic system to achieve precise matching for optimal performance.Ease of maintenance and operation comfort
The machine is equipped with a 10.1-inch intelligent touchscreen, offering multiple working mode selections, as well as features such as an electric heating air-suspension seat and a high-power air conditioning system. The machine provides a spacious maintenance area, allowing for easy access during inspections and maintenance.Adaptability to diverse working conditions
It can be configured with a range of working devices such as rock buckets, ultra-powerful booms, rippers, and a variety of buckets to meet different working condition requirements.| Operating weight | 97800kg |
| Engine power | 571/1800kW/rpm |
| Bucket capacity | 6.5m³ |
| External dimensions | 13720*4200*4990mm |
| Bucket rod digging force | 417kN |
| Bucket digging force | 480kN |
| Rotating speed | 0-6.9r/min |
| Travel speed | 2.8/4.1km/h |
| Maximum digging height | 12735mm |
| Maximum digging distance | 12620mm |
| Maximum digging depth | 7150mm |
| Emissions | Eu stage IIIAIndicated as per international standards |
